Camera Packaging Box | Pulp Cradle Builds for Bodies and Lenses, MOQ 100
- Material: Greyboard rigid or litho-laminated E-flute, moulded pulp cradle
- Structure: Two-level build, body suspended above, accessories below
- MOQ: 100 pcs
- Lead time: 15-20 working days | Free dieline
Custom camera packaging boxes for irregular, heavy devices - moulded pulp cradle profiled around the lens mount, separate accessory tray, ISTA drop tested at true filled weight. MOQ 100 pcs.
Our Advantages
No Die and Plate Charges For Digital Samples
High quality printing
Quick Turn Around
Starting from 100pcs
Custom size and style
Competitive Price
Free Design Support
To door delivery
REQUEST A QUOTE
COMPANY SERVICES
| Bigger Discounts Offer for large orders | Bigger Discounts Offer for large orders Prices are negotiable based on your purchase volume and Fixated prices can be offered based on frequency of the order. |
| After-service | Sample cost is refundable if it's not good quality as we promised!We will refund you the defected goods values as contract listed,if the defective goods are beyond as we contracted.Our goal is to have no bad feedback and keep doing business in the future! |
| Risk Free, Quality Assurance | We've Sate of the art production facility and all printed jobs are run through our strict quality assurance department, so there are no quality complaints. |
| Printed Method | We use Off-set printing to achieve excellent printing results. However, Digital and screen printing is also available depending on box requirements. |
| About Us | Guangzhou Ecopaperbox established in 2011 is undoubtedly an accredited manufacturer of custom boxes which are exactly according to the needs and desires of the clients. Our top priority is meeting the needs and requirements of our customers. Custom Packaging and printing are provided to the customers with excellent quality on the regular basis so that maximum benefit can be achieved in the minimum amount of time. All boxes that made of paperboard, we can produce. You are welcome to make inquiry via info@ecopaperbox.com and contact us at +8619927709433. |
What Is a Camera Packaging Box?
A camera pack is an awkward engineering problem: the device is heavy, irregularly shaped, has protruding optics, and ships with a set of loose accessories that all need to be immobilised. Unlike a flat laptop or a small earbud case, a camera body concentrates weight in one lobe and puts a lens barrel where the box wants to be flat.
The protruding element is what governs the design. A lens mount or a fixed barrel means the cradle has to support the body around the protrusion rather than under it, and any drop energy must be routed away from the mount, which is usually the most expensive part to damage. This is why camera packs almost always use moulded pulp or profiled foam rather than a flat tray.
The second issue is accessory count. A typical camera ships with a battery, charger, strap, body cap, cable and manual - six items that will migrate and scratch the body if they share a compartment. A two-level build with the body suspended above and the accessories seated below is the standard answer.
Which Industries Use This Box, and How It Is Specified
Camera and optics packaging is specified by weight distribution and by protrusion.
| Industry / use case | How we normally spec it |
|---|---|
| Mirrorless and DSLR bodies | Rigid or litho-laminated build with a moulded pulp cradle profiled around the lens mount, plus a lower accessory tray. |
| Lens packaging | Cylindrical cavity in pulp or profiled foam, with end caps supported so the glass never rests on the mount. |
| Action cameras | Small rigid box or windowed carton with a die-cut paperboard tray for the camera, mounts and adhesives. |
| Instant and film cameras | Litho-laminated E-flute with bold graphics; the category is gift-led, so shelf presence matters more than restraint. |
| Drone and gimbal kits | Larger multi-cavity pulp tray holding the airframe, controller, props and batteries in separate seats. |
| Kit bundles | Body plus lens in one pack, either two pulp cavities or a body pack and a lens pack inside a printed outer. |
Lithium batteries shipped with the product bring UN3481 marking and airline documentation requirements. We add the marking panel to the dieline, but the shipping declaration is the shipper responsibility.
Material Specification
Weight, protrusions and drop sensitivity put every camera pack into a rigid or litho-laminated construction.
| Component / stock | Specification |
|---|---|
| Rigid greyboard core | 1.5-3mm greyboard (chipboard) from 80-100% recycled fibre, wrapped in 128-157gsm printed art paper. This is the standard consumer-electronics build - a rigid box, not a folding carton. |
| Litho-laminated E-flute | 1.5mm microflute with a printed litho face. Used when the pack has to survive shipping on its own but still carry photographic artwork. |
| Moulded pulp insert | Recycled paper pulp cradle moulded to the device profile. Now the default replacement for EVA and vac-formed PET, and the option most electronics buyers ask for first. |
| Die-cut paperboard tray | Folded paperboard cavity for lighter devices and accessories. Keeps the pack mono-material and costs less than pulp tooling on short runs. |
| EVA / foam insert | Still used where drop performance is critical or the device is heavy and irregular. Protective, but it ends any single-material recycling claim. |
| Anti-static consideration | For bare PCBs and components, an ESD-safe bag or a carbon-loaded liner is specified separately - plain paperboard is not anti-static. |
Sustainability notes
- Moulded pulp instead of EVA foam or vac-formed PET is the single largest sustainability improvement available in electronics packaging, and it usually performs as well in drop tests.
- The greyboard core of a rigid electronics box is already 80-100% recycled fibre.
- Soy-based inks and water-based glue throughout; no solvent adhesives anywhere in the build.
- A paper pull-tab or a fibre-based ribbon replaces the plastic film tab used on most premium unboxing structures.
- Right-sizing the cavity to the device reduces both board and void fill, and lowers dimensional-weight freight at the same time.
Structure and Size Options
The cradle geometry does the work here - the shell is comparatively straightforward.
| Option | What it changes |
|---|---|
| Box build | Rigid lid and base, shoulder-neck, or litho-laminated E-flute where the pack ships alone. |
| Cradle | Moulded pulp profiled around the lens mount, or profiled foam where drop performance is critical. A flat tray is not adequate for a camera body. |
| Accessory level | Separate lower tray with individual seats for battery, charger, strap, cap and cable so nothing migrates onto the body. |
| Optics protection | Recessed seat that keeps the lens mount and any glass surface clear of every internal wall. |
| Battery marking | UN3481 lithium battery panel printed on the outer where a battery ships inside the pack. |
| Transit testing | ISTA-style drop testing at the true filled weight, with the actual body rather than a uniform dummy. |
Send the actual body with the lens or cap fitted as it will ship. Camera bodies have complex surfaces and a cradle cut from a drawing rarely supports the load in the same places as one cut from the real object.
Printing and Finishing
- Offset CMYK - photographic artwork, gradients and product imagery.
- Pantone spot colour - exact brand colour matching, up to 6 colours plus varnish.
- Digital printing - the reason we can hold MOQ at 100; no plate cost on short runs.
- Hot foil stamping - gold, silver, rose gold, holographic. The most requested logo finish.
- Emboss / deboss - raised or recessed logo, with or without foil.
- Spot UV - gloss varnish over a matte laminate to pick out a logo or pattern.
- Finishes - matte, gloss, soft-touch, anti-scratch lamination or aqueous varnish.
Ordering: MOQ, Dieline and Lead Time
| Item | Detail |
|---|---|
| MOQ | 100 pcs per size and per design |
| Dieline | Free. We send a print-ready structural dieline to your designer before you commit to anything. |
| Pre-production sample | Plain structural sample in 3-5 days, printed sample in 5-7 days. Sample cost is credited against the bulk order. |
| Production lead time | 15-20 working days for rigid builds after artwork and sample sign-off |
| Artwork format | AI or PDF, CMYK, 300dpi, 3mm bleed, fonts outlined, placed on our dieline |
| Shipping | Pack ships assembled; specify whether an outer shipper is used, as it changes the drop-test target. |
Moulded pulp tooling is a one-off amortised over the programme. At launch volumes of 100-500 pcs a die-cut corrugated suspension cradle usually costs less overall, and we quote both so the comparison is explicit.
Related Packaging
Other electronics packaging
Laptop Boxes | Router Boxes | Earphone Boxes | Smartwatch Boxes
Shipping and heavy-duty structures
Printed Shipping Boxes | Tear-Off Corrugated Boxes | Drawer and Sleeve Box | Rigid Gift Boxes
Surface Choice
Our Guangzhou custom packaging factory runs four-color offset printing, automatic lamination, die-cutting and rigid box assembly on one floor. In-house production keeps lead times short and print color consistent from the first sample to full volume. Buyers are welcome to request a video tour or a factory audit before placing an order.
Packing Method For Corrugated Packaging:
Generally no need to put the PE bags inside of the cartons. Since the boxes are glued a layer of cardboard, generally production time is not long enough to dry the paper box. If you tie the PE bags, the steamed water pearl will be produced inside of the bags.
Product Details
- Custom sizes & shape – made to your exact dimensions, flute and box style.
- Eco-friendly board – recyclable corrugated / kraft material with low-migration inks on request.
- Secure closure – self-locking or magnetic options keep contents safe in transit.
- Full-surface printing – CMYK, Pantone, foil, emboss and spot UV available.
- Low MOQ & fast turnaround – start from 100–500 pcs with 7–15 day lead time.
Customer Reviews
The Camera Packaging Boxes arrived exactly as proofed. Print quality is sharp and the structure is sturdy - our customers loved the unboxing.
Fast turnaround and helpful dieline support. The Camera Packaging Boxes fits our product perfectly and the price was fair at our MOQ.
Clean printing on eco-friendly board and smooth communication. We will reorder the Camera Packaging Boxes for our next campaign.
Frequently Asked Questions
Why does a camera need a moulded pulp cradle rather than a flat tray?
Because a camera body concentrates weight in one lobe and has a protruding lens mount. A flat tray lets the body rock and routes drop energy straight into the mount, which is the most expensive part to damage. A pulp cradle supports the body around the protrusion and carries the load away from the optics.
How do you stop accessories scratching the camera body?
By putting them on a separate level. A camera typically ships with six loose items - battery, charger, strap, cap, cable, manual - and any of them sharing a compartment with the body will migrate and mark it. The standard build suspends the body above and seats the accessories in individual cavities below.
Do you need the actual camera to make the insert?
Yes, and fitted with the lens or body cap exactly as it will ship. Camera bodies have complex compound surfaces, and a cradle cut from CAD data rarely bears the load in the same places as one cut from the physical object. It is the difference between a cradle that supports and one that merely contains.
What about shipping lithium batteries inside the pack?
A UN3481 marking panel goes on the outer carton and we lay it into the dieline. The declaration, airline documentation and any state-of-charge limits are the shipper responsibility, but we make sure the marking has correctly sized, unobstructed space on the box.
Is moulded pulp worth the tooling cost at low volume?
Often not at launch. Pulp tooling is a one-off amortised over the programme, so at 100-500 pcs a die-cut corrugated suspension cradle usually works out cheaper overall and performs well. We quote both routes with the drop-test results so the trade-off is explicit rather than assumed.
What is your MOQ and lead time for camera boxes?
100 pcs, 15-20 working days for rigid builds after artwork and sample sign-off. Add time if pulp tooling is being cut for the first time. The structural dieline is free and comes to you before you commit.
